WATER SHIELD

Air Circulator with Water Shield Drum

Our water shield air circulator with water shield drum is perfect for those who need an outdoor fan with oscillation. The powerful motor and gearbox are made to support the drum without extra load on the motor. The drum itself is made of high-quality steel and is further finished with powder coating. This enhances the durability of the drum.

  • Outdoor Sustainability: Water shield air circulator with water shield drum performs very well in outdoor environments such as restaurants, hotels, and clubhouses.
  • Efficient And Quiet Operation: They not only perform efficiently, but they also perform quietly.
  • Low Noise Levels: Due to the above feature, they are perfect for places where maintaining peace is important.
  • Mist Kit Compatibility: In order to better the cooling feature, mist kits can be conveniently installed in these water shield air circulator fans.
  • Weather Protection: Our water shield air circulator with water shield drum is modelled to face challenging weather conditions like rain and dust, and thereby protect the fan motor.
  • Different Sizes: These fans come in different sizes – 16″,18″, 20″, and 24″ – which makes it quite convenient for placement in different places.
  • Easy Assembly Process: These water shield air circulator with water shield drums are super easy to assemble, which makes the whole process more user-friendly.
  •

Performance figures HD Wall Fans

MODEL
WALL FAN
HP
RPM
WATTAGE
AIR DELIVERY
18-HDWF-D
18" Oscillating
1/6
1400/1200/1000
100W
150 M³/Min
20-HDWF-D
20" Oscillating
1/6
1400/1200/1000
120W
140 M³/Min
24-HDWF-D
24" Oscillating
1/4
1400/1200/1000
200W
263 M³/Min
30-HDWF-D
30" Oscillating
1/4
1400
250W
370 M³/Min

Performance figures generally conforming to IS:2997 Due to continuous development and innovation, the above specifications are subject to change

Performance figures HD Pedestal Fans

MODEL
PEDESTAL
HP
RPM
WATTAGE
AIR DELIVERY
18-HDPF-D
18" Oscillating
1/6
1400/1200/1000
100W
150 M³/Min
20-HDPF-D
20" Oscillating
1/6
1400/1200/1000
120W
140 M³/Min
24-HDPF-D
24" Oscillating
1/4
1400/1200/1000
200W
263 M³/Min
30-HDPF-D
30" Oscillating
1/4
1400
250W
370 M³/Min

Performance figures generally conforming to IS:2997 Due to continuous development and innovation, the above specifications are subject to change

Performance figures CD Wall Fans

MODEL
WALL FAN
HP
RPM
WATTAGE
AIR DELIVERY
18-CDWF-D
18" Oscillating
1/6
1400/1200/1000
100W
150 M³/Min
20-CDWF-D
20" Oscillating
1/6
1400/1200/1000
120W
140 M³/Min
24-CDWF-D
24" Oscillating
1/4
1400/1200/1000
200W
263 M³/Min
30-CDWF-D
30" Oscillating
1/4
1400
250W
370 M³/Min

Performance figures generally conforming to IS:2997 Due to continuous development and innovation, the above specifications are subject to change

Performance figures CD Pedestal Fans

MODEL
PEDESTAL
HP
RPM
WATTAGE
AIR DELIVERY
18-CDPF-D
18" Oscillating
1/6
1400/1200/1000
100W
150 M³/Min
20-CDPF-D
20" Oscillating
1/6
1400/1200/1000
120W
140 M³/Min
24-CDPF-D
24" Oscillating
1/4
1400/1200/1000
200W
263 M³/Min
30-CDPF-D
30" Oscillating
1/4
1400
250W
370 M³/Min

Performance figures generally conforming to IS:2997 Due to continuous development and innovation, the above specifications are subject to change
